SG90 9g Micro Servo for Small Aircraft Models
THE BENEFITS OF CHOOSING US
Description
The SG90 9g Micro Servo for Small Aircraft Models delivers 1.6kg·cm @4.8V with a 0.1s/60° @4.8V transit time, running on 4.8V.
It is built with a Nylon train, not waterproof construction, 9g weight.
A conventional brushed DC motor keeps the cost down and the torque curve predictable, which suits general-purpose RC and robotics use.
Rated for 4.8V: confirm that your BEC or receiver pack can supply the stall current of this servo before you install it, especially if you are driving several servos from one source.
Operating angle is available in 180°, so the same body can be ordered for standard control-surface work or for winch and robot-joint applications that need more than 180°.
This torque class suits 1:16–1:18 cars, small fixed-wing models, micro robot arms and camera gimbals, where weight matters more than holding force.
Ordering for a build or a distribution line? Tell us the torque, voltage range and connector you need and we will quote it. See also the full Yadovex range and our guides on choosing 6S long-range motors and 7-inch vs 9-inch propulsion.
Key specifications
| Torque | 1.6kg·cm @4.8V |
| Speed | 0.1s/60° @4.8V |
| Voltage Range | 4.8V |
| Operating Angle | 180° |
| Motor Type | Analog |
| Gear Material | Nylon |
| Waterproof Rating | Not Waterproof |
| Weight | 9g |
The SG90 is a compact 9g micro servo with nylon gears, ideal for small electric aircraft models and lightweight DIY projects. It delivers 1.6kg·cm of torque at 4.8V with a fast 0.1s/60° response, offering a great balance of price and performance.
Note: Due to its compact size and lower pulling force, this servo is recommended for ordinary small electric aircraft models only. It is not recommended for large fixed-wing aircraft or electric helicopters.
Specifications
| Model | SG90S |
| Servo Type | Micro Servo |
| Torque | 1.6 kg·cm @4.8V |
| Operating Speed | 0.1s/60° @4.8V |
| Operating Voltage | 4.8V |
| Operating Angle | 180° |
| Dead Band | 10μs |
| Gear Material | Nylon |
| Operating Temperature | 0°C ~ 55°C |
| Weight | 9g |
This product is intended for lawful use only (aerial photography, agriculture, industrial inspection, education, and recreational FPV / RC applications). Please check and comply with all applicable local, national, and international laws and regulations in your country/region before purchase and use, including drone, aviation, export, and import regulations.
By purchasing, you confirm the product will be used for legal purposes only. Yadovex reserves the right to decline orders that we believe may be used for prohibited purposes. For our full policy, see our Disclaimer and Compliance & Export Control Policy.
Related models and guides
Browse: Micro Servos | all RC servos
Related ranges: brushless waterproof servos | robot arm and bionic hand servos | micro servos
Read: Brushless vs Brushed Motors for Drones
Frequently asked questions
What torque does the 9g servo deliver?
It is rated at 1.6kg-cm @4.8V. Transit time is 0.1s/60° @4.8V. This torque class suits 1:16 to 1:18 cars, small fixed-wing models, micro robot arms and camera mounts.
What voltage does this servo need?
It runs 4.8V. Check that your BEC or receiver pack can supply the stall current before you install it.
Is this servo waterproof?
This model is not sealed, so keep it away from water. For wet conditions choose a waterproof servo from our brushless waterproof range.
Do you supply these servos in bulk?
Yes. We supply samples for validation and then repeat bulk orders with custom wiring, connectors and OEM packaging.
Related products in this range
D5545GS 45KG Coreless Waterproof Digital Servo for RC Models | DC5515 15KG Waterproof Digital Servo for RC Cars & Boats | DC5525 25KG Waterproof Digital Servo for RC Cars & Boats
Additional information
| Torque | 1.6kg·cm @4.8V |
|---|---|
| Speed | 0.1s/60° @4.8V |
| Voltage Range | 4.8V |
| Operating Angle | 180° |
| Motor Type | Analog |
| Gear Material | Nylon |
| Waterproof Rating | Not Waterproof |
| Weight | 9g |
| Dead Band | 10μs |
| Operating Temperature | 0°C ~ 55°C |
