F2207.5 1750KV FPV Racing Brushless Motor
The Yadovex F2207.5 Brushless Motor (1750KV) is designed for FPV racing, 5 inch freestyle drones. OEM/ODM customization and bulk supply are available.
THE BENEFITS OF CHOOSING US
Description
The Yadovex F2207.5 Brushless Motor (1750KV) is a high-performance brushless motor designed for FPV racing, 5 inch freestyle drones. Built for reliable power output and stable operation, it delivers consistent thrust with low noise and high efficiency.
Engineered with precision winding and quality materials, this motor offers smooth startup, strong torque, and durable construction for demanding flight conditions. It is suitable for both sample testing and bulk production needs.
Specifications
| Model | F2207.5 1750KV |
| KV Rating | 1750KV/1950KV/2550KV |
| Voltage Range | 4S-6S LiPo |
| Motor Weight | 34g |
| Shaft Diameter | |
| Max Power | 704W |
| Peak Current | |
| Propeller | GF6030 |
| Motor Dimensions | 27.1 x 18.1mm |
| Configuration | 12N14P |
| Lead Wire | 20# 200mm |
| Idle Current | 1.1A |
Yadovex supports OEM and ODM customization, including motor KV, shaft size, cable length, connector type, propeller adapter, logo marking, packaging, and bulk order requirements.
Need a custom solution or bulk quotation? We support OEM/ODM customization, sample testing, and bulk supply for drone motors and UAV parts. Contact us: sales@yadovex.com | WhatsApp: +86 134 3230 0164
This product is intended for lawful use only (aerial photography, agriculture, industrial inspection, education, and recreational FPV / RC applications). Please check and comply with all applicable local, national, and international laws and regulations in your country/region before purchase and use, including drone, aviation, export, and import regulations.
By purchasing, you confirm the product will be used for legal purposes only. Yadovex reserves the right to decline orders that we believe may be used for prohibited purposes. For our full policy, see our Disclaimer and Compliance & Export Control Policy.
Related models and guides
Same range: 2807 1300KV FPV Racing Bru | SF2306 1750KV FPV Racing B | Shu2306 FPV Freestyle Brus
Browse: FPV Racing & Freestyle Motors | all drone motors
Read: How to Choose FPV Drone Motors for 6S Long-Range Drones
Read: Outrunner vs Inrunner Brushless Motors | Brushless vs Brushed Motors for Drones
Frequently asked questions
What does the 2207 in F2207.5 mean?
2207 describes the stator: 22 mm diameter and 7 mm stack height. A larger stator gives more torque and heat capacity, which is what lets the motor turn a bigger propeller.
What propellers suit the F2207.5 1750KV motor?
It is designed for GF6030. Check the thrust table for your exact propeller and cell count before you size the power system.
What battery does the F2207.5 1750KV run on?
4S-6S LiPo. Confirm the pack continuous rating covers the hover current with margin.
What ESC does the F2207.5 1750KV need?
Size the ESC above the maximum current in the thrust table, with headroom for heat.
Do you supply the F2207.5 1750KV in bulk?
Yes. We supply samples for validation and then repeat bulk orders with custom KV, cable length, connectors and OEM packaging.
